Brakes

Shimano Deore M6120 4 Piston Disc

Drivetrain

Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed / 10-51t

Fork

FOX 36 Float Performance Air Grip 3 3-Modes / Kabolt 15x110mm axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 150mm travel

Frame

Genius Carbon / IMP Technology / HMF Main Frame BB92 / Alloy SL 6011 swingarm VLK Virtual 4 Link kinematic 27.5in (2.6 & 2.8) and 29in (2.4 & 2.6) tire compatible with Geo-BB adj. SW dropouts for Boost 12x148mm TBC Trunnion box construction

Rear Shock

FOX NUDE T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom large air volume / DPS / Reb. Adj. Travel 150-100-Lockout / 185X55mm

Seatpost

Syncros Duncan Dropper Post 2.5 31.6mm / S size 100mm / M size 125mm / L & XL size 150mm

Wheels

Syncros Revelstoke 2.5 6 Bolt F: 15x110mm, R: 12x148mm 30mm Tubeless ready rim 28H / Micro Spline Syncros Axle w/Removable Lever with Tool
