Brakes

Shimano XT M8120 4 Piston Disc

Drivetrain

SRAM GX / Eagle 12 Speed / 10-52 T

Fork

FOX 38 Float Performance Elite Air / FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle 44mm offset / tapered steerer / Reb. Adj. / Lockout / 170mm travel

Frame

Ransom Carbon / IMP Technology / HMX Main Frame BB92 / Alloy SL 6011 swingarm VLK Virtual 4 Link kinematic 29in (2.4 & 2.6) tire compatible with Geo-BB adj. SW dropouts for Boost 12x148mm TBC Trunnion box construction

Rear Shock

FOX NUDE TR EVOL Trunnion Contessa Custom Tune w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom Ramp Adjust with linear and progressive settings DPS / Reb. Adj. Travel 170-120-Lockout / 205X65mm

Seatpost

FOX Transfer Performance Elite Dropper Post 31.6mm / S 125mm / M 150mm / L 175mm

Suspension

Full Suspension

Wheels

Syncros Revelstoke 2.0 6 Bolt F: 15x110mm, R: 12x148mm Boost 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool
